Product Details
- Place of Origin: Shandong, China (Mainland)
- Brand Name: CNBADA
- Model Number: BDDR315
- Weight: 25.000 kg
- :
- :
- :
- :
- :
- :
- :
Quick Details
Place of Origin: Shandong, China (Mainland)
Brand Name: BADA
Model Number: BDDR315
Voltage: 175V~240V
Power: 3KW
Frequency: 50Hz
Welding Area: Below 315mm
Dimensions: DN50~DN315
Weight: 25KG
Usage: Electrofusion welding
After-sales Service Provided: Engineers available to service machinery overseas
Color: Orange and blue
Warranty: One year
Availiable welding range: The diameter below 315mm
Total Volume: 0.07m³
Total Weight: 29.4KG
Material: high quality iron
Weld Method: Electrofusion welding machine
Apply To: sanitation, water, natural gas and others
Package: standard export wooden cases
Video teaching: YES
Packaging & Delivery
| Packaging Details: | The goods are packaged by three composite material standard export wooden cases after plastic film packaging. |
|---|---|
| Delivery Detail: | Shipped in 2 days after payment |
315 Electrofusion welding machine ---Application:
PE pipes welding machine;
HDPE pipes welding machine;
STEEL WIRE NET PE COMPOSITE pipes welding machine;
PP pipes welding machine;
PB pipes welding machine;
any other plastic pipes available for welding... ...
315 Electrofusion welding machine ---Further parameters:
Model | BDDR-315W | BDDR-800W |
Welding material | PE solid wall tube compatible Steel mesh skeleton tube
| Steel mesh skeleton tube compatible PE solid wall tube
|
Welding range | DN50-DN315 | DN50-DN800 |
Supply Voltage | 175V-240V 50Hz | Single-phrase power 220V |
Constant voltage/output voltage | 10V-50V | 10V-200V |
Constant voltage/output current | 5A-60A | 5A-50A |
Max. output power | 3.0KW | 10.0KW |
Ambient temperature | -15º~ 50º | -15º~ 50º |
Relative humidity | ≤80% | ≤80% |
Time Range | 1-9999 S | 1-9999 S |
Time Resulution | 1 S | 1 S |
Time Accuracy | 0.10% | 0.10% |
Output voltage accuracy | 1% | 1% |
Our advantages:
1. The raw material of the machine frame is aluminum ZL104, it is light but strong, is one of the best material for machine.
2. The main electrical apparatus elements are best of china, imported from abroads.
3. Removable PTFE coated heater with separate temperature control system,temperatur can be controlled to a minimum range.
4. The electric facer adopts reversible double cutting edge blades, which can make the cutting effect more perfect.
Our Services
1. One year warranty, life-long maintenance.
2. In warranty time, if nonartificial reason damaged can take old change new for free. Out of warranty time, we can offer maintenance service (charge for material cost).
3. Engineers available to service machinery overseas but all the costs to the buyer to pay.
Company Information
JINAN BADA PLASTIC PIPE WEDLING EQUIPMENT CO.,LTD is a leader manufacturer specialized in butt welding machine in china.
It has built up an excellent brand image and gotten above 80% domestic market and export to more than 40 countries since entered to China in 2009 .
We own a complete range of international standard butt fusion equipment including field welding machine, workshop fitting machine, pipe cutting saw, all the optional parts and tools required under the ISO9001 quality system as well as CE certification.
