Specifications
electrofusion welding machine1.Intelligent system,easy operation
2.lower failure rate
3.welding plastic pipe
4.CE&ISO
Verified Supplier
Jinan Bada Plastic Pipe Welding Equipment Co., Ltd.
| Factory
Experience:2009-11-09
Buyer Protection
- Guaranteed Secure Payments on Every Order
- Refund if your item is not delivered or as described
- Buyer Protection after order confirmation
Latest Browsing
Product Details
- Place of Origin: Shandong, China (Mainland)
- Brand Name: CNBADA
- Model Number: BDDR-800
- Weight: 35.000 kg
- :
- :
- :
- :
- :
- :
- :
Quick Details
Place of Origin: Shandong, China (Mainland)
Brand Name: BADA
Model Number: BDDR-800
Voltage: 220V
Power: 10KW
Frequency: 50Hz
Welding Area: DN50~DN800
Dimensions: The diameter below 800mm
Weight: 15KG
Usage: Electrofusion welding
After-sales Service Provided: Engineers available to service machinery overseas
Color: orange
Warranty: one year
Available welding range: the pipe diameter below 800mm
Total Volume: 0.16m³
Total Weight: 35KG
Material: high quality iron
Weld Method: Electrofusion welding machine
Apply To: sanitation, water, natural gas and others
Package: standard export wooden cases
Video teaching: YES
Packaging & Delivery
| Packaging Details: | The goods are packaged by three composite material standard export wooden cases after plastic film packaging |
|---|---|
| Delivery Detail: | 1 day |
1.Intelligent system,easy operation
2.lower failure rate
3.welding plastic pipe
4.CE&ISO
800 Electrofusion welding machine ---Application:
STEEL WIRE NET PE COMPOSITE pipes welding machine;
PE pipes welding machine;
HDPE pipes welding machine;
PP pipes welding machine;
PB pipes welding machine;
any other plastic pipes available for welding... ...
800 Electrofusion welding machine ---
Specifications:
Model | BDDR-315v | BDDR-800v |
Welding material | PE solid wall tube compatible Steel mesh skeleton tube
| Steel mesh skeleton tube compatible PE solid wall tube
|
Welding range | DN20-DN315 | DN20-DN800 |
Supply Voltage | 175V-240V 50Hz | Single-phrase power 220V |
Constant voltage/output voltage | 10V-50V | 10V-200V |
Constant voltage/output current | 5A-60A | 5A-50A |
Max. output power | 3.0KW | 10.0KW |
Ambient temperature | -15º~ 50º | -15º~ 50º |
Relative humidity | ≤80% | ≤80% |
Time Range | 1-9999 S | 1-9999 S |
Time Resulution | 1 S | 1 S |
Time Accuracy | 0.10% | 0.10% |
Output voltage accuracy | 1% | 1% |
Our advantages:
1. The raw material of the machine frame is aluminum ZL104, it is light but strong, is one of the best material for machine.
2. The main electrical apparatus elements are best of china, imported from abroads.
3. Removable PTFE coated heater with separate temperature control system,temperatur can be controlled to a minimum range.
4. The electric facer adopts reversible double cutting edge blades, which can make the cutting effect more perfect.
Our Services
1. One year warranty, life-long maintenance.
2. In warranty time, if nonartificial reason damaged can take old change new for free. Out of warranty time, we can offer maintenance service (charge for material cost).
3. Engineers available to service machinery overseas but all the costs to the buyer to pay.
Company Information
JINAN BADA PLASTIC PIPE WEDLING EQUIPMENT CO.,LTD is a leader manufacturer specialized in butt welding machine in china.
It has built up an excellent brand image and gotten above 80% domestic market and export to more than 40 countries since entered to China in 2009 .
We own a complete range of international standard butt fusion equipment including field welding machine, workshop fitting machine, pipe cutting saw, all the optional parts and tools required under the ISO9001 quality system as well as CE certification.
- Place of Origin: Shandong, China (Mainland)
- Brand Name: CNBADA
- Model Number: BDDR-800
- Weight: 35.000 kg
- :
- :
- :
- :
- :
- :
- :
800 Electrofusion welding machine ---
Specifications:
Model | BDDR-315v | BDDR-800v |
Welding material | PE solid wall tube compatible Steel mesh skeleton tube
| Steel mesh skeleton tube compatible PE solid wall tube
|
Welding range | DN20-DN315 | DN20-DN800 |
Supply Voltage | 175V-240V 50Hz | Single-phrase power 220V |
Constant voltage/output voltage | 10V-50V | 10V-200V |
Constant voltage/output current | 5A-60A | 5A-50A |
Max. output power | 3.0KW | 10.0KW |
Ambient temperature | -15º~ 50º | -15º~ 50º |
Relative humidity | ≤80% | ≤80% |
Time Range | 1-9999 S | 1-9999 S |
Time Resulution | 1 S | 1 S |
Time Accuracy | 0.10% | 0.10% |
Output voltage accuracy | 1% | 1% |
