Product Details
- Place of Origin: Shandong, China (Mainland)
- Brand Name: CNBADA
- Model Number: SHBD1600
- Weight: 7000.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
Quick Details
Condition: New
Place of Origin: Shandong, China (Mainland)
Brand Name: BADA
Model Number: SHBD1600
Input Voltage: 380V
Current: 50Hz
Power: 62.2KW
Dimensions: 1200mm~1600mm
Usage: welding plastic pipe
Certification: CE&ISO
After-sales Service Provided: Engineers available to service machinery overseas
Color: red or blue or other
Warranty: one year
Available welding diameter:1200mm~1600mm
Total Volume: 18.4m³
Total Weight: 7000KG
Material: Aluminum
Weld Method: hydraulic butt fusion welding machine
Apply To: sanitation, water, natural gas and others
Package: standard export wooden cases
Video teaching: YES
Packaging & Delivery
| Packaging Details: | The goods are packaged by composite material standard export wooden cases after plastic film packaging. |
|---|
1600 hdpe pipe butt fusion welding machine--Application:
PE pipes welding machine;
HDPE pipes welding machine;
PP pipes welding machine;
PB pipes welding machine;
PVDF pipes welding machine;
any other plastic pipes available for welding... ...
1600 hdpe pipe butt fusion welding machine---Further parameters:
Model | SHBD1600 | SHBD1000 | SHBD1200 |
Welding diameters (mm) | 1200,1600 | 710,800,900,1000 | 800,900,1000,1200 |
Heating plate temperature | 270°C | 270°C | 270°C |
Heating plate surface | <±12°C | <±10°C | <±10°C |
Pressure adjustment range | 0-18MPa | 0-18MPa | 0-18MPa |
Cross-sectional area of the cylinder | 6870mm2 | 2512mm2 | 3297mm2 |
Working voltage | 380V,50Hz | 380V,50Hz | 380V,50Hz |
Heating plate power | 47KW | 21.7KW | 30KW |
Milling cutter power | 5.5KW | 3KW | 3KW |
Hydraulic station power | 9.7KW | 3KW | 3KW |
Lifting power | --- | 1.1 KW | 1.5 KW |
Total Power | 62.2KW | 22.5KW | 37.5KW |
1600 pe hdpe butt fusion welding machine --- Operation instruction
The od card which matches the pipes must be used. Stuck the pipe tightly then fix them on the rack.
Open the ends of pipes,put in the milling cutter, and fix the milling cutter on the rack. Start the milling cutter, mover forward the cylinder,close the fixture and cut the ends. when it forms into thecontinuous chips, lower the pressure to zero firstly, then open the fixture and close the milling cutter at last.
Put down the milling cutter, close the ends, and check up the pipe of the two ends. Check up the temperature of the heating plate. For the first welding, the temperature of the heating plate should be heated over the pre-heated temperature . Every time for welding, the heating plate must be cleaned.
Put the heating plate with the suitable temperature on the rack, close the fixture, make the end meets the end meets the heating plate fully and set the system pressure.
When the end raises uniformly and the height of the crimps meet the requirements, the heating time should be lowered at the same time.
When it get to the endothermic time, open the fixture quickly and remove the heating plate.
Close the fixture quickly, adjust the pressure uniformly in the specified time and write down the cooling time.The pressure should be kept until the ends cool down completely.
When it gets to the cooling time, adjust the pressure to zero, open the fixture, and remove the welded pipe.
Our advantages:
1. The raw material of the machine frame is aluminum ZL104, it is light but strong, is one of the best material for machine.
2. The main electrical apparatus elements are best of china, imported from abroads.
3. Removable PTFE coated heater with separate temperature control system,temperatur can be controlled to a minimum range.
4. The electric facer adopts reversible double cutting edge blades, which can make the cutting effect more perfect.
Our Services
1. One year warranty, life-long maintenance.
2. In warranty time, if nonartificial reason damaged can take old change new for free. Out of warranty time, we can offer maintenance service (charge for material cost).
3. Engineers available to service machinery overseas but all the costs to the buyer to pay.
Company Information
JINAN BADA PLASTIC PIPE WEDLING EQUIPMENT CO.,LTD is a leader manufacturer specialized in butt welding machine in china.
It has built up an excellent brand image and gotten above 80% domestic market and export to more than 40 countries since entered to China in 2009 .
We own a complete range of international standard butt fusion equipment including field welding machine, workshop fitting machine, pipe cutting saw, all the optional parts and tools required under the ISO9001 quality system as well as CE certification.
